Features & Benefits:

• OTDR (Optical Time Domain Reflectometer) – Single-mode OTDR with a dynamic range of 22/20 decibels (dB), capable of testing over a range of 80 kilometers, equipped with SC/PC or FC/PC optical interfaces.
• Optical link intelligent analysis – OTDR software offers comprehensive test reports including Reflective Event, Reduce Event, Fiber Splitter, and Fiber End analyses.
• OPM (Optical Power Meter) – Measures optical power within a range of -50 to +26 decibel milliwatts (dBm) with six wavelength calibration capabilities.
• VFL (Visual Fault Locator) – Emits red light with an output power of 10 milliwatts (mW).
• Wire Mapping – Identifies faults such as short circuits, open circuits, and cross-connections in LAN cables.
• Length Test – Measures cable lengths ranging from 1 to 600 meters.
• Lamp – Provides a reliable light source for illumination in dim working environments.
• Rechargeable battery – Features a battery standby time exceeding 11 hours, tested for approximately 6 hours of continuous use, with a capacity of 4000 milliampere-hours (mAh), and charges via Micro USB at 5 volts and 2 amperes (A).

Product Specs:

OTDR

• Wavelength: 1310/1550nm
• Fiber Type: G.652 SM Fiber
• Dynamic Range: 24dB/22dB
• Event Blind Zone : 10m
• ATT Blind Zone: 15m
• Test Range: 10m-60km
• Pulse Width: 5ns-10us
• Ranging Accuracy: ±(1m+Sampling Interval+0.005%xTest Distance)
• Loss Accuracy: ± 0.2dB/dB
• Sampling Points: 16k-128k
• Sampling Resolution: 0.05~8m
• Reflection Accuracy: ±3dB
• Data Storage: Internal: 2600: External: TF Card
• Laser Safety Level: Class Il level
• File Format: SOR Standard File Format
• Connector: FC/PC (Interchangeable SC、ST)or FC/APC (Interchangeable SC, ST)
